Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

Product Categories
Sichuan Shouke Agricultural Technology Co., Ltd.
Contact Now

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

Brand Name : HengShou

Certification : ISO SGS

Place of Origin : Sichuan

MOQ : 1

Price : $19900-39900 Sets

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 Sets Years

Delivery Time : 10 Work Days

Product name : Pomace Mesh Belt Dryer

Product Features : Dehydration drying

Heating method : Electric heating, steam heating, hot air heating

Product details : Strong integration ability

Dimension(l*w*h) : Customized according to material

Color : Customized

Contact Now

Multifunctional Stainless Steel Door Lock Hinged Pomace Mesh Belt Dryer

Description:

  1. Small investment, fast drying speed, and high evaporation intensity;
  2. High efficiency, large output, and good product quality;
  3. In standardized production, the number of segments can be increased according to the output;

Pomace Mesh Belt Dryer drying equipment that uses steel mesh as a conveyor belt to carry materials for continuous drying is suitable for flow operation. Since the conveyor belt is in the form of a mesh, it is suitable for drying regular or irregular lumps (such as coal lumps, various mineral powders, food, vegetables, etc.). This machine can be used with other equipment. Can also be used alone.

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

COMPANY PROFILE

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

PATENT CERTIFICATE

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Multifunctional Pomace Mesh Belt Dryer Machine 4Layer Stainless Steel Door Lock Hinged
